Clutch Pedal
Clutch Pedal
Couldn't load pickup availability
The PRL Clutch Pedal adds a realistic, adjustable clutch feel to the PRL pedal platform, with a regressive force response designed to simulate real clutch plate engagement.
With adjustable travel, force, pedal face position, and bite point behaviour, the clutch can be tuned from a smoother road-car style response to a more aggressive motorsport-inspired feel.
Show More
Show More
Realistic regressive clutch force response
Adjustable bite point position
Optional aggressive cam profile included
Full-throw pedal force adjustable from approximately 15 kg to 40 kg
CNC-machined 6061 aluminium pedal arm and face
Laser-cut 304L stainless steel base structure
Shielded ball bearings and PTFE-lined rod ends
Plug-and-play compatibility with the PRL pedal system
Made in the Netherlands
Specifications
Specifications
Full throw end-stop adjustment:10° to 25°
Linear travel range:27.5 mm to 74.9 mm
Minimum full-throw pedal force:Approx. 15 kg
Maximum full-throw pedal force:Approx. 40 kg Overall dimensions at default pedal height214.5 × 78 × 245.9 mm Pedal face dimensions:63 × 100 mm
Mass:1.43 kg
What’s Included
What’s Included
Dark green spring (stiffer)
Alternative cam profile (more aggressive response)
